Product Details:
Payment & Shipping Terms:
|
| Product Name: | Infusion Set | Material: | PP PE PVC ABS |
|---|---|---|---|
| Needle Connector: | Luer Slip And Luer Lock | Tube Length: | 1.35 To 2 M |
| Spike: | With Or Without Air Vent | OEM: | OK |
| Injection Port: | Y Port Or Flash Bulb Injfection | Needle: | With Or Wihout |
| Sterilization: | EO Gas | Shelf Life: | 5 Years |
| Highlight: | disposable medical supplies,disposable medical items |
||
Disposable Medical Products Transfusion IV Infusion Set Customized
INFUSION SET
It includes a subcutaneous cannula, adhesive mount, quick-disconnect, and a pump connector.
An infusion set is used with an insulin pump as part of intensive insulin therapy. The purpose of an infusion set is to deliver insulin under the skin. It is a complete tubing system to connect an insulin pump to the pump user: it includes a subcutaneous cannula, adhesive mount, quick-disconnect, and a pump connector.
Consist of
1. Piercing device-Made of medical grade white ABS, with or without air
Inlet, 3 or 4 holes size according to ISO8536-4 standard.
2. Protective cap-Made of PP or PE.
3. Drip chamber-Made of soft PVC, size according to ISO8536-4 Standards, 4.5cm-7cm in length.
4. Fluid filter-Support is made of ABS or PE, nylon net, mesh size: 15 micron.
5. Air inlet-Cap is made of red, white, or blue PP
6. Water-repellent filter-PP support, hydrophobic filtering paper, made of
Acrylic resin and nylon.
7. Flow regulator-Made of PP or ABS, normal shape, small size or Horned shape, large size.
8. Injection site-Latex cone, rubber cone, synthetic rubber cone, Y Site-made of hard transparent PVC+injection site made of natural or Synthetic rubber.
9. Soft tubing-Made of soft medical grade PVC, 3x4mm, 150cm in
Length, or adjust according to requirements.
10. Terminal connector: Made of PE, PVC, luer lock or luer slip.
11. Components assembly: By gluing with solvent cyclohexanone
